Open MS Skid 80 LPH RO system
Representative 80 LPH Model

Open MS Skid 80 LPH

Purification Capacity
80 litres per hour
Technology
Reverse osmosis system
Application
Suitable for brackish water
Membrane
HJC 300 GPD × 2
Pump
0.5 HP CRI ClaRO 50 AC pump
Maximum Operating TDS
Below 2000 PPM
Operating Voltage
220 V AC
Product Dimensions
830 (H) × 260 (W) × 460 (L) mm
80 LPH Range Details

Practical Features Across the Category

These points summarize the practical capabilities available across the 80 LPH domestic RO range. Exact values vary by model and configuration.

  • 80 LPH output: suitable for high-use households, offices and light commercial requirements.
  • Two practical formats: classic open frame and open MS skid configurations.
  • Two 300 GPD membranes: used on the representative open-skid model.
  • Below 2000 PPM operating TDS: suitable for selected brackish-water applications.
  • 0.5 HP AC pump: CRI ClaRO 50 pump on the representative configuration.
  • Multi-stage filtration: 10-micron, 20-inch GAC, 5-micron and post-carbon filtration.
  • More than 40% recovery: measured at approximately 27°C ± 2°C.
  • Open-skid equipment: three 20-inch housings, one pressure gauge and five-metre tube sets.
